Rated size |
|
| 28 | 35 | 55 | 63 | 75 | 85 |
Displacement HMV-02 can be set to 0 cc/rev displacement | Maximum Vmax . | cc/rev | 28.6 | 35.6 | 54.7 | 63 | 75.9 | 85.6 |
Minimum Vmin only for variable and regulating motors | cc/rev | - | - | 18.3 | - | 25.3 | - | |
Speed | Max. operating speed at Vmax | rpm | 4500 | 4500 | 4300 | 3900 | 3800 | 3600 |
Maximum speed at Vmax* | rpm | 4800 | 4800 | 4400 | 4200 | 4100 | 3850 | |
Max. operating speed at Vmin | rpm | - |
| 4700 | - | 4400 | - | |
Maximum speed at Vmin* | rpm | - |
| 5300 | - | 5000 | - | |
Pressure | Nominal pressure | bar | 450 | |||||
Maximum pressure** | bar | 500 | ||||||
Permissible housing pressure | bar | 2.5 | ||||||
Torque | Output torque ( | Nm | 196 | 244 | 374 | 431 | 519 | 586 |
Power | Corner power (theoretical) | kW | 92 | 115 | 161 | 176 | 207 | 221 |
Permissible shaft loads | Axial input /output force | N | 2000 | |||||
Radial | N | on request | ||||||
Perm. housing temp. | Perm. housing temperature with minimum perm. viscosity > 10 cSt | °C | 105 | |||||
Weights | Fixed displacement motor with 2-hole mounting flange | kg | 16 | 16 | 19 | 24 | 26 | 33 |
Variable and regulating motor with 2- or 4-hole mounting flange | kg | - | - | 28 | - | 32 | - | |
Moment of inertia | kgm2 x 10-2 | 0.25 | 0.25 | 0.49 | 0.72 | 0.79 | 0.97 | |
p=430 bar)
